    Singlemode Simplex Fiber Optic Patch Cord G652D Type 1550nm

    Ask Lasest Price
    Brand Name : SUNET/OEM
    Model Number : SUNET01
    Certification : ISO9001
    Price : USD 0.3-0.5 PER PCS
    Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 500000 pcs per month
    Delivery Time : 3-8 work days
    • Product Details
    • Company Profile

    Singlemode Simplex Fiber Optic Patch Cord G652D Type 1550nm

    Best Quality Singlemode Simplex Fiber Optic Patch Cord


    Patch Cord Description


    Patch Cord facilitate rapid deployment of high density backbone cabling in data centers and other high fiber environment, reducing network in stallation or reconfiguration time and cost. It's build with the highest quality components , Low loss elite versions are offered, featuring low insertion low for demanding high speed networks where power budgets are critical.


    Patch Cord Applications

    1.Optical Distribution Frame
    2.Computer Networks
    3.Fiber Optic Communication Systems
    4.Optical Access Networks
    5.Local Area Network
    6.Fiber Optic Sensors

    Patch Cord Technical specifications


    Parameters

    Standard Fiber Cable Assemblies

    Fiber Type

    SM(G.652/G.657A)

    MM(OM1/OM2/OM3)

    Jacket Materials

    LSZH/OFNR/PVC

    Connector Type

    SC/LC/ST/LC/MU/MTRJ/MPO/E2000

    Ferrule Materials

    Ceramic

    Testing Wavelengths

    1310±30/1550±30nm

    850±30/1300±30nm

    Insertion Losss(dB)
    TIA/EIA-455-107

    ≤ 0.2dB
    (PC/UPC/APC)

    ≤ 0.3dB
    (PC/UPC)

    Return Loss(dB)
    TIA/EIA-455-107

    ≥45dB(PC/UPC)
    ≥55dB(APC)

    ≥35dB(PC/UPC)

    Exchangeability

    ≤ 0.2dB

    Cable Assemblies

    Simplex

    Operating Temperature (° C)

    -10~ + 70

    Storage Temperature (° C)

    -40 ~ +85

    Package

    1unit/bag

    *All values specified are with connectors.
