Fiber Optic 48 Core Ftth Termination Box Indoor Waterproof IP65

Product Categories

Qingdao Sunet Technologies Co., Ltd.

Contact Now

Fiber Optic 48 Core Ftth Termination Box Indoor Waterproof IP65

Ask Lasest Price
Brand Name :	SUNET
Model Number :	SUNET-11
Certification :	ISO14001/ISO900
Price :	USD 2-3 per piece
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	20000 per month
Delivery Time :	5-8 days

Add to Cart

Product Details
Company Profile

Fiber Optic 48 Core Ftth Termination Box Indoor Waterproof IP65

Waterproof IP65 Ftth Fiber Optic 48 Core Distribution Box Ftth Indoor Termination Box

Description

The Optical Distribution Box is used as a termination point for the feeder cable to connect with drop cable in FTTx communication network system. The fiber splicing, splitting, distribution can be done in this box, and meanwhile it provides solid protection and management for the FTTx network building.

Features:

1.Total enclosed structure, be in nice shape.
2.Material: PC+ABS or ABS, wet-proof, water-proof, dust-proof,
anti-aging.
3.Clamping for feeder cable and drop cable, fiber splicing,
fixation, storage, distribution…etc. all in one.
4.Cable, pigtails, patch cords are running through own path without
disturbing each other, cassette type SC adapter installation, easy
maintenance.
5.Distribution panel can be flipped up, feeder cable can be placed
in a cup-joint way, easy for maintenance and installation.

Dimension(LxWxH)mm315X235X95mm
Fiber Count16Cores
InstallationWall mounting(outdoorindoor),
Pole Mounting
Level of ProtectionIP65
Cable EntriesSupporting Uncut
Max Cable DiameterMax Input =φ15mm, Max output =2x3mm
Configuration16pcs SC adapter and
16pcs Double LC and 2 pcs 1*8 Blockless PLC

Packing Information
(For Reference Only)
GW:13Kg QTY:20PCS
MEAS:490X460X330mm

Fiber Optic 48 Core Ftth Termination Box Indoor Waterproof IP65
