AI-9 Fiber Optic Fusion Splicer for FTTH FTTB FTTX Network

    Buy cheap AI-9 Fiber Optic Fusion Splicer for FTTH FTTB FTTX Network from wholesalers

    Buy cheap AI-9 Fiber Optic Fusion Splicer for FTTH FTTB FTTX Network from wholesalers
    • Buy cheap AI-9 Fiber Optic Fusion Splicer for FTTH FTTB FTTX Network from wholesalers

    AI-9 Fiber Optic Fusion Splicer for FTTH FTTB FTTX Network

    Ask Lasest Price
    Brand Name : SUNET
    Model Number : AI-9
    Certification : iso9001
    Price : USD 500-680 PER PCS
    Payment Terms : L/C, D/A, D/P, T/T, MoneyGram, Western Union
    Supply Ability : 5000 pcs per month
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    AI-9 Fiber Optic Fusion Splicer for FTTH FTTB FTTX Network

    AI-9 Hot Sale Fiber Optic Fusion Splicer


    Product Description

    Signal Fire AI-9 adopts the latest core alignment technology with auto focus and six motors, it is a new generation of fiber fusion splicer. It is fully qualified with 100 km trunk construction, FTTH project, security monitoring and other fiber cable splicing projects. The machine uses industrial quad-core CPU, fast response, is currently one of the fastest fiber splicing machine in the market; with 5-inch 800X480 high-resolution screen, the operation is simple and intuitively; and up to 300 times focus magnifications, making it is very easy to observe the fiber with naked eyes. 5 seconds speed core alignment splicing, 15 seconds heating, the working efficiency increased by 50% compared to ordinary splicing machines.


    Specification


    Fiber alignment
    Core/cladding alignment / Manual alignment
    Splicing time
    5S
    Heating time
    15S
    Heating mode
    Automatic heating (Preheating)
    Focus mode
    Six motors Auto focus
    Applicable Fibers
    SM[G.652&G.657),MM (G.651) ,DS(G.657), NZDS (G.655)
    Splice Loss
    0.025dB (SM),0.01dB (MM) 0.04dB (DS/NZDS)
    Control technology
    Real-time control and calibration of fusion ARC
    Return loss
    Better than 60DB
    Fiber diameter
    Cladding Diameter: 80-150um Coating Diameter: 100-1000um
    Fiber Cleave Length
    Coating less than 250um: 8-16mm Coating less than 250-1000um:16mm
    Builtin lighting
    easy for night operation
    Tension Test
    easy for night operation
    Fiber holders
    3in 1 fiber holder, SM. MM, bare fiber, pigtail, rubber-insulated, multi fiber cable
    Magnification
    300 for XorY view, 150 forX or Y view
    Screen
    5 inch TFT color display
    Splicing Mode
    Normal / high precision splicing
    Splicing record storage
    Synchronize to the phone, the server to coud storage unlimited
    Bult-in battery
    7800 mA high-capacity lithium battery, charging time≤3.5 hours, continuous splicing and heating about 260 times
    Power supply
    Input AC100-240V 50 / 60HZ, output DC13.5V / 4A. the current power mode can be identifled, real-time detection of battery power
    Operating Conditions
    Temperature -15~ +50 C,Working altitude:0 ~ 5000m, Resist max. wind speed:≤15m/s
    Shrinkable tube
    60mm,40mm
    Visual Fault Locator
    Power:15mw.2hzflashing And Constantly Bright Mode
    Optical Power Meter
    Wavelength:850nm,1300nm,1310nm, 1 490nm,1550nm, 1 625nm Measuring Range:-70 ~ + 6db Absolute Error:
